1
Purpose
To define the part numbering guidelines for TRIMECH TECHNOLOGY PTE
LTD. This procedure serves as a reference to define part number for TRIMECH
TECHNOLOGY PTE LTD internal use.
Scope
Applicable to all components, documents, software, and others related materials
which are used by TRIMECH TECHNOLOGY PTE LTD.
Procedure
To ease the complexity and increase the efficiency of the part numbering system,
each defined part number should follow the following general format.
Prefix Alphanumeric Characters
The prefix serves as the header definition of a particular part number. It defines a
group of materials with the same features and characteristics. In normal situation
the definition of prefix should be limited to only 2 characters, and it should be the
short form of a particular material. For example, the prefix for batteries is defined
as BT, while the prefix for lamps is defined as LP.
The alphanumeric characters serve to differentiate the materials with the same
prefix. In normal situation the alphanumeric characters should be limited to only
20 characters. The definition of the alphanumeric characters of the materials is
separated into 3 groups. The first group is the not commonly used material group,
while the second group is the commonly used material group, and the third group
is the TRIMECH’s own material group.
1.1 Not Commonly Used Material Group
The not commonly used materials are materials which used for only once or a few
times. To ease the complexity in searching new alphanumeric characters for these
materials, the vendor’s part numbers of the materials is used as the alphanumeric
characters in the part numbering system. As an example, a lamp with vendor’s
part number APW199-R is defined as LP-APW199-R in TRIMECH part
numbering system.
1.2 Commonly Used Material Group
The commonly used materials are materials which commonly used in the projects.
These types of materials cover a wide variety of different characteristic in size,
capacity, shape, and others different features which requires more attention in
TRIMECH TECHNOLOGY PTE LTD
Work Instruction Prepared By:
ShanJie
Dongyun
Reviewed & Approved: (ME/EE/SW):
Page: 1 of 2
XH Chen MS Toy Thomas Yang
TRIMECH TECHNOLOGY PTE LTD
Part Numbering Guidelines
Doc. No
TWI73PD77
Rev.
E
Date:
6th Jan 2009
2
defining its alphanumeric characters. It should be note that the alphanumeric
characters’ definition of these materials should contain information in describing
the material’s feature and characteristic. An example of such material will be nuts
shown in appendix page 41.
The prefix of nuts is NT. A part number NT-M3N contains information whereby
this material is a nut. M3 refers to 3 metric. N refers to nylon. Hence from the part
number, one can tells that it is a nylon nut with size of 3 metric. Please refer to
page 41 for more information of nuts.
1.3 TRIMECH Own Material Group
This group defines the materials developed and owned by TRIMECH. Examples
are the programs and manuals.
The following diagram summarizes the whole part numbering system.
TRIMECH TECHNOLOGY PTE LTD
Work Instruction Prepared By:
ShanJie
Dongyun
Reviewed & Approved: (ME/EE/SW):
Page: 2 of 2
XH Chen MS Toy Thomas
Yang
TRIMECH TECHNOLOGY PTE LTD
Part Numbering Guidelines
Doc. No
TWI73PD77
Rev.
E
Date:
16th Dec 2008
Prefix Alphanumeric Characters
1.The length of prefix,
otherwise state,
should limit to 2.
2.It should be the short
form of the material.
Limit to 20 characters only.
Not commonly used
material group
Commonly used
material group
TRIMECH own
material group
3
APPENDIX
Part listing
Ball Retainer ....................................................................................................................... 5
Battery ................................................................................................................................ 6
Brochure .............................................................................................................................. 7
Bundle ................................................................................................................................ 8
Bushing ............................................................................................................................... 9
Buzzer ............................................................................................................................... 10
Cables Assembly ............................................................................................................... 11
Cable ................................................................................................................................ 12
Camera .............................................................................................................................. 13
Capacitor ........................................................................................................................... 14
Connector .......................................................................................................................... 15
Controller .......................................................................................................................... 16
Converter.......................................................................................................................... 17
Crystal ............................................................................................................................... 18
Caster Wheel ..................................................................................................................... 19
Cylinder............................................................................................................................ 20
Diode ................................................................................................................................ 21
Driver ............................................................................................................................... 22
Drawing/Diagram ............................................................................................................. 23
Equipment ......................................................................................................................... 24
Fuse Holder ....................................................................................................................... 25
Floating Joint .................................................................................................................... 26
Fuse .................................................................................................................................. 27
Gear .................................................................................................................................. 28
Gauge ............................................................................................................................... 29
Heater Cartridge ................................................................................................................ 30
Integrated Circuit .............................................................................................................. 31
Keypad .............................................................................................................................. 32
Label ................................................................................................................................ 33
Labour Cost ....................................................................................................................... 34
LED .................................................................................................................................. 35
Light Fiber ........................................................................................................................ 36
License .............................................................................................................................. 37
LCD Module ..................................................................................................................... 38
Lens .................................................................................................................................. 39
Lamp ................................................................................................................................ 40
Light Source ...................................................................................................................... 41
Manual .............................................................................................................................. 42
Mechanism ........................................................................................................................ 43
Fabricated Part .................................................................................................................. 44
Metal Part .......................................................................................................................... 45
Manifold ............................................................................................................................ 46
Motor................................................................................................................................ 47
4
Monitor ............................................................................................................................. 48
Nut.................................................................................................................................... 49
Optic ................................................................................................................................. 50
PCB .................................................................................................................................. 51
Personal Computer ............................................................................................................ 52
Pneumatic Fitting .............................................................................................................. 53
Pneumatic Speed Controller, Silencer and Tubing ........................................................... 54
Program ............................................................................................................................. 55
Pin .................................................................................................................................... 56
Plastic Part ........................................................................................................................ 57
Power Supply .................................................................................................................... 58
Regulator ........................................................................................................................... 60
Ring .................................................................................................................................. 61
Relay ................................................................................................................................ 62
Rotation Stage ................................................................................................................... 63
Rubber Part ....................................................................................................................... 64
Shock Absorber ................................................................................................................. 65
Sensor ............................................................................................................................... 66
Spring ............................................................................................................................... 67
Socket ............................................................................................................................... 68
Software List ..................................................................................................................... 69
Software Package .............................................................................................................. 70
Screw................................................................................................................................ 71
Switch ............................................................................................................................... 72
Thermocouple ................................................................................................................... 73
Transformer...................................................................................................................... 74
Terminal ............................................................................................................................ 75
Work Instruction ............................................................................................................... 76
Valve ................................................................................................................................ 77
Vacuum Accessory ........................................................................................................... 78
Vibration Machine Mount................................................................................................. 79
Variable Resistor/Varistor ................................................................................................ 80
Wire.................................................................................................................................. 81
Washer .............................................................................................................................. 82
5
Ball Retainer
BAR-X
Example Part Number Description
BAR-M81015 Ball Retainer, ID=8mm, OD=10mm,L=15mm
Note: The alphanumeric charaters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: JunSiong 01st Dec 2008.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters (1)
6
Battery
BT-XXX-XX
Example Part Number Description
BT-LIT-3V 3V lithium coin cell battery
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Alphabet Voltage
7
Brochure
BC-XXXXXX-XX
Example Part Number Description
BC-TM1800-0 Brochure for TM-1800
Prefix Machine model
number
Serial number /
alphabet
8
Bundle
BD-XXXXXX-XX
Example Part Number Description
BD-A08020.40 Bundle, Fiber Optic Single type 40"length 2"Dia
Note: The Alphabets/Number is the same with the vendor’s part number.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Alphabet/Number Length
9
Bushing
BU-X - X
1 Symbol Description 2 Symbol Description
DIA Outer Diameter _ Inner
Diameter (mm)
L Length (mm)
Example Part Number Description
BU-DIA1310-L12 Bushing, ID=10, OD=13mm, L=12mm
Generated by: JunSiong 01st Dec 2008.
Rev A – Page 1 of 1
Prefix
Oscillation
Frequency
Optional
10
Buzzer
BZ-XXX-X
Example Part Number Description
BZ-KPE-232 Buzzer, PC board mount Piezo 3-20V
BZ-KPE-272 Buzzer, PC board mount Piezo 3.5kHz 3-28V
Note: The Alphabet/Number is the same with the vendor’s part number.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Alphabet
Numbers
11
Cables Assembly
CA-R 10 L4-X
1 Symbol Description
C Core
R Ribbon
A Coaxial cable
T Thermocouple
W Welding cable
O Others
Example Part Number Description
CA-C2L315-001 Cable assembly, 2 cores, 315mm, 5 pin free plug.
Generated by: Pauline Leung on 9th Oct 2003.
Rev A – Page 1 of 1
Prefix Length
(mm)
Type of cable
(1)
Size/ no
of ways
Series
Numbers/
Alphabets
12
Cable
CB-C 10-X
1 Symbol Description
C Core
R Ribbon
X Coaxial cable
T Thermocouple
W Welding cable
O Others
Example Part Number Description
CB-C16-G20 Cable, 16 cores, gauge size 20.
CB-C3-8AWG Cable, 3 core, 8 AWG
Generated by: Pauline Leung on 9th Oct 2003.
Rev A – Page 1 of 1
Prefix Type of cable
(1)
Size/ no
of ways
Series
Numbers/
Alphabets
13
Camera
CM-X
Example Part Number Description
CM-AVC566N CCTV Colour Camera – NTSC, AVTECH
CM-MUC1000M Camera CCD - 1280x1024 - Monochrome – USB,
VIMATIC
CM-XC-ST30CE Camera CCD Sony XC-ST30CE, NOVA
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Oct 2007.
Prefix
Alphanumeric
Characters
14
Capacitor
CP-XXXX-XXXV-X-X
Prefix:
CP = Capacitor
Capacitance Value:
Value in Farad.
Indicate the value in unit style like 100nF instead of decimal point for a 0.1uF capacitor.
Voltage:
Voltage Value in unit V.
Material:
T = Tantalum
P = Plastic Film Cap
C = Ceramic Cap
E = Electrolytic
Series Numbers/Alphabets:
Further description (e.g. the package).
Example:
Part Number Description
CP-10uF-35V-T 10uF 20% 35V Tantalum Radial 0.2
CP-100nF-63V-P 100nF 20% 63V Plastic Film Cap Radial 0.2
Prefix Capacitor Value Voltage Series Numbers
/Alphabets
Material
15
Connector
CN-DB25-M-X
1 Symbol Description Example 2 Symbol Description
IDC# IDC Connector CN-IDC16-F-1 M Plug
BNC BNC Connector CN-BNC-F-1 F Socket
DB25 DB25 Connector CN-DB25-M-1 O Others
DB9 DB9 Connector CN-DB9-M-1
FP# Free Plug CN-FP6-M-1
B#HD Boxed Header CN-B8HD-M-1
HDIL# Header-Dual In Line CN-HDIL4-M-1
HSIL# Header-Single In Line CN-HSIL4-F-1
DIL# Dual In Line CN-DIL8-M-1
SIL# Single In Line CN-SIL4-M-1
TCJ Thermocouple Type J CN-TCJ-M-1
TCK Thermocouple Type K CN-TCK-F-1
O Others CN-O-M-1
Example Part Number Description
CN-B10HD-M Boxed Header, 10 Ways, Plug
Prefix
Standard
(1)
Socket /
Plug (2)
Series
Number /
Alphabet
16
Controller
CTL-X
Example Part Number Description
CTL-ADVIPC1 IPC-P4 2.4G,DDR256,6PCI/1ISA, 4 USB
Extension
CTL-AL-27 Dimmer- Air Lux-AL 27
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
17
Converter
CV-X
Example Part Number Description
CV-NMH0512S DC-DC Converter module 5V to +/-12V SIL 5
CV-USB-RS232 USB to serial converter
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
18
Crystal
XT-X - X
Example Part Number Description
XT-22.1184MHZ XTAL- HC-49/U (Crystal 22.1184MHz) (RoHS)
XT-16.0000MHZ-DIL8 XTAL-DIL8 SINGLE OUTPUT 16MHZ Crystal
(RoHS)
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters (1)
Alphanumeric
Characters (2)
19
Caster Wheel
CW-X
Example Part Number Description
CW-ACC-JM075HP Caster wheel fix direction w/o brake, JM075HP
CW-AMM-20(M16x2) Anti machine vibration mount, M16x2.0x150L
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
20
Cylinder
CY-X
Example Part Number Description
CY-CDM2F25-50ADC76L
Cylinder, Bore 25mm Stroke 50mm CDM2F25-
50A-DC76L
CY-CDM2WF25-25AC76L
Cylinder, Double Acting Double Rod Bore 25mm
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
21
Diode
DI-X
Example Part Number Description
DI-1N4001 1.0 Ampere 50V General Purpose Rectifier Lead-
Free (RoHS)
DI-1N4148 Signal Diode 1N4148 Axial (RoHS)
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
22
Driver
DR-X
Example Part Number Description
DR-IMS51-120 Driver, for 230VAC 5 phase stepper driverMotor
DR-MR-J2S-200A Driver, Amplifier for 1.5kW Servo Motor
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
23
Drawing/Diagram
DW-XXXX
Example Part Number Description
DW-0079 Engineering notes for TM72 P Controller
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Number of
drawing/diagram
24
Equipment
EP-X
Example Part Number Description
EP-EMP-30 Universal Device Programmer
EP-FLUKE50D Digital Thermometer Dual Fluke
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
25
Fuse Holder
FH-20x5-X
Example Part Number Description
FH-20x5 Fuse holder for 20 x 5mm fuse, rear panel mount, finger
release, 5A, 230V, panel diameter 10mm
Generated by: Lawrence on 16th Oct 2003.
Rev A – Page 1 of 1
Series number /
Alphabets
Dimension for
fuse to fit into
fuse holder
Prefix
26
Floating Joint
FJ-X
Example Part Number Description
FJ-JA10-4-070 Floating joint M4X0.7-Cylinder bore 10mm
FJ-JA20-8-125 Floating joint M8X1.25
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
27
Fuse
FU-2A5-GL-X
1 Symbol Description
GL Glass
CE Ceramic
O Others
Example Part Number Description
1 FU-2A5-GL-X Fuse 2.5A, size = 20 x 5mm, quick blow, glass
2 FU-5A-GL-X Fuse 5A, size = 20 x 5mm, quick blow, glass
3 FU-A5-GL-X Fuse 0.5A, size = 20 x 5mm, quick blow, glass
Generated by: Lawrence on 16th Oct 2003.
Rev A – Page 1 of 1
Current Rating Series number /
Alphabets
Prefix Type of
Material (1)
28
Gear
GR-X
Example Part Number Description
GR-DS-1-20 Gear-DS-1mm Pitch - 20 Teeths
GR-DS-1-50 Gear-DS-1mm Pitch - 50 Teeths
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
29
Gauge
GU-X
Example Part Number Description
GU-GP46-10-01L5 Pressure gauge guide with switch GP46 series, 1/8
port size, 24V LED
GU-GP46-10-02L5 Pressure gauge guide with switch GP46 series, 1/4
port size, 24V LED
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
30
Heater Cartridge
HT-X
Example Part Number Description
HT-21-8320W250-Q0008320 Heater Cardtridge, 2" length, 250W, build in
terminal
HT-HS8331 W250-Q0123302 Heater Cardtridge, 250W
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
31
Integrated Circuit
IC-X
Example Part Number Description
IC-27C512-70 EPROM CMOS 512K (64K X 8) 70ns
IC-74HC05 Hex Inverters With Open-Collector Outputs Dip14
IC-87C51RD Microcontroller DIP40 64KB OTP 1KB RAM
(RoHS)
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
32
Keypad
KP-X
Example Part Number Description
KP-207-275 Tile Set 'A', non-illuminated Farnell #207-275
KP-5051-08 KEYPAD CONNECTOR 8 PINS
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
33
Label
LB-X
Example Part Number Description
LB-12345-6789 Label, Warning - Moving Parts
LB-HIGH-VOLTAGE Label, Danger - High Voltage
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
34
Labour Cost
LC-TM-28S-I
1 Symbol Description
I Indirect
- Direct
Example Part Number Description
1 LC-TM-28S Labour Cost for TM-28S
2 LC-TM-28S-I Indirect Labour Cost for TM-28S
Generated by: Terence Koh on 5th Dec 2006.
Rev A – Page 1 of 1
Type of
Labour
Cost (1)
Prefix
Machine Model
name
35
LED
LD-X-X
Example Part Number Description
LD-GREEN-5 5mm Standard Green LED 20mA (RoHS)
LD-RED-3 3mm Standard red led 20mA, Ultra bright-Radial
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Dimension
Colors/Others
36
Light Fiber
LF-X
Example Part Number Description
LF-A08530 Light Fiber, Dual and Quad Bundle
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
37
License
LI-X
Example Part Number Description
LI-OCR Easy OCR add license for Picolo Board
LI-EIL Easy Image License for picolo card
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
38
LCD Module
LM-X
Example Part Number Description
LM-320240-TV Graphics LCD Module with Touch Screen - Top
View
LM-LTM084P363 Toshiba 8.4"inches LCD Touchscreen
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
39
Lens
LN-X
Example Part Number Description
LN-A08080 Lens, Spot for standard bundles
LN-LM50NCL Lens, Camera 2/3" 50MM/F2.8 KOWA
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
40
Lamp
LP-X
Example Part Number Description
LP-APW199-R Pilot Light-Flat Head-Dia 22mm-Red
LP-PRPZ-402-RYGB Menics, tower light w buzzer, 4 colour, DC24V
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
41
Light Source
LS-X
Example Part Number Description
LS-A20510 Light Source, A20510
LS-A20800.2-DDL Light Source 150W-DDL- Input power -
230V~240V-50Hz~60Hz
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
42
Manual
MA-X-RevX
Example Part Number Description
MA-TM29M Operation Manual for TM29M
MA-TM-78-RevB Operation manual TM-78 Pull Test Machine Rev B
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Revision Machine’s part (optional)
number
43
Mechanism
MC-X
Example Part Number Description
MC-HC05-1 perma-tork, OD36,length of shaft19.5
MC-HC2-25J perma-tork, OD47,length of shaft6.3
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
44
Fabricated Part
MEC XXXXXX XXXX
Example Part Number Description
MEC001753TM101P-MKIII BASIC PLATE (SHT 3)
MEC001716TM-101-PRMKIII
Safety Cover (SHT96)
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Updated by: Hu dongyun on Oct 2008
RevB-Page 1 of 1
Prefix Machine’s part
number (Optional)
6 digit reference
number
45
Metal Part
ML-X
Example Part Number Description
ML-BA10-BK-L03A Axis Combination Bracket
ML-OS36SM-MR Mounting Ring
ML-Z01-14X80 Guide pillar, length80mm, dia14mm
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
46
Manifold
MN-X
Example Part Number Description
MN-MFU4-A05R-M5 Manifold 4 station, Adex
MN-MFU5-A05R-M5 Manifold 5 station
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
47
Motor
MO-X
Example Part Number Description
MO-86BYG450A-01 Stepper motor L61mm, 1.7A 1/ 1.6.N.m
MO-CM1-C-23L20-1.08 Cool Muscle motor ver 1.08
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
48
Monitor
MT-X-X
Example Part Number Description
MT-10"-COLOUR 10" monitor, colour for 50 and 60 HZ
MT-10.4"-TFT 10.4" TFT LCD Monitor with LG Panel (VGA/SVideo/
Video)
MT-9"-BW Monitor, 9", B/W, LTC2009/51-PHILIP , SSM-
930CE- SONY OR TC-4410, 50Hz
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Dimension COLOUR/BW/TFT
49
Nut
NT-M3S-X
1 Symbol Description 2 Symbol Description
- Inches B Brass
M Metric N Nylon
S Stainless Steel
O Others
Example Part Number Description
NT-M5S Nut, M5, Stainless Steel
NT-M3N Nut, M3, Nylon
NT-M4B Nut, M4, Brass
Generated by: Daniel Teo on 16th Oct 2003.
Prefix
Unit Of
Measurement
(1)
Size
Material
(2)
Series
Numbers/
Alphabets
50
Optic
OP-X
Example Part Number Description
OP-30414-10 Optical filter blue colour
OP-30414-2 Optical filter green colour
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
51
PCB
PCB-X-RevX
Example Part Number Description
PCB-0038 4 Channel Temperature Data Logger
PCB-0040-revC Breakout Board for Mark3 Main Controller Card
RevC
Note: The reference number is the same as the vendor’s part number.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Revision (Optional)
Reference Number
52
Personal Computer
PC-X
Example Part Number Description
PC-GEME-V2000-X34 General Embedded Machine with Video Capture -
Celeron-650-Intel 815E
PC-GENE-8310 XP Embeded Controller gene-8310
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
53
Pneumatic Fitting
PF-FR-D6M5-X
1 Symbol Description 2 Symbol Description
F Fittings
E Elbow
S Straight
T Union T
Y Union Y
R Reducer
O Others
3 Symbol Description
M Metric thread (mm)
- Taper pipe thread (inch)
Example Part Number Description
PF-FE-D61/4-S Fitting, Male elbow dia6mm 1/4" thread with sealant
PF-FE-D61/8 Fitting, Elbow, Dia 6mm, 1/8"
Generated by: Pauline Leung on 2nd Oct 2003.
Rev A – Page 1 of 1
Prefix
Size Thread Size
(3)
Type of
pneumatic
fittings (1) Subgroup
(2)
Series
Numbers/
Alphabets
54
Pneumatic Speed Controller, Silencer and Tubing
PF-FR-D6D4M5-X
1 Symbol Description 2 Symbol Description
S Speed controllers
E Elbow
L Silencer
S Straight
T Tubing
T Union T
Y Union Y
A Antistatic
R Reducer
O Others
3 Symbol Description
M Metric thread (mm)
- Taper pipe thread (inch)
Example Part Number Description
PF-SS-D4M5 Speed Controller, Straight, Dia 4mm, M5.
PF-TA-D6 Astistatic Tubing Dia 6mm, Black
Generated by: Pauline Leung on 2nd Oct 2003.
Rev A – Page 1 of 1
Prefix
Size Thread Size
(3)
Type of
pneumatic
fittings (1) Subgroup
(2)
Size
Series
Numbers/
Alphabets
55
Program
PG-XXXXXXXX-X
Example Part Number Description
PG-TM-101PR-MKIII Program code for TM-101PR-MKIII
PG-TM-101PR-MKIII-20p Program code for TM-101PR-MKIII
20Program
The following are to be created into ZIP file and hyper link to the respective entry in the
Access:
1. Source Code
2. Hex File
3. User Interface
4. User Structure
5. Version History
6. Others related to software
For Version History, programmer has to update when new changes have done to modify
the old version. The following data has to be stated clearly:
1. Actual logo shown on the display of the machine.
2. Date release for the program
3. Version number for the new program
4. Changes make.
Generated by: Lawrence Ma on 28th Nov 2003.
Rev A – Page 1 of 1
Prefix Actual logo shown on the
display of the machine. E.g.
TM-101PR-MKIII
Series
Numbers/
Alphabets
56
Pin
PI-X
Example Part Number Description
PI-DIA-4x25DOWEL_S/S DOWEL PIN -S/S
PI-SHF-001T-0.8SS PIN FOR CONNECTOR FEMALE
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Updated by: Hu dongyun on 5th Sep 2007
Rev B – Page 1 of 1
Prefix
Alphanumeric
Characters
57
Plastic Part
PL-X
Example Part Number Description
PL-2441-151 Orange Adjustable Clamping Lever M6 Length
20mm
PL-A4-297x210 Card Case A4 297mmx210mm
PL-C401AS 5mmx1000mmx2000mm - static dissipative DC
plate-transparent clear-PVC
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
58
Power Supply
PS-X
Example Part Number Description
PS-25W-D Power Supply-Dual output-5/24V-25W
PS-S-150-24 150W single output 24V,6.5A
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
59
Resistors
RE-XXX-X%-XXW-X
Prefix:
RE = Resistor
Resistance Value:
Value in Ohms.
Indicate the value in unit style like 6R8 instead of decimal point for a 6.8R Resistor.
Tolerance:
Resistance Tolerance Value in unit %.
Wattage:
Resistance Wattage in unit W.
Indicate the value in unit style like 0W5 instead of decimal point for 0.5W.
As for 1/4W (common value), it is not necessary to indicate the value in Part Number.
Series Numbers/Alphabets:
Further description (e.g. the package).
Example:
Part Number Description
RE-180R-5%-0W5 Resistor, Carbon Film 180 ohms 5% 1/2W, axial, 1/4 size
RE-6K8-1% Resistor, Metal Film 6.8Kohms 1% 1/4W axial, 1/4 size
Prefix Series Numbers/
Alphabets
Resistance Value Tolerance Wattage
60
Regulator
RG-X
Example Part Number Description
RG-B07-201-MIKG Regulator- Pressure
RG-ITV-0050-3BL Electro-Pneumatic Regulator with Flat Bracket,
Right Angle
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
61
Ring
RI-X
Example Part Number Description
RI-13.3x2.4 O Ring, Dia13.3mm x 2.4mm
RI-STW-22 Retaining Ring Basic 20.5mm, Tol +-0.2
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
62
Relay
RL-X
Example Part Number Description
RL-G6A-434P-US-24VDC G6A series PCB relay
RL-KHAU-17D11-24 General purpose relay
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
63
Rotation Stage
RT-X
Example Part Number Description
RT-AX4022 ABSODEX (Absolute Detecting System)
RT-CDRB1BW10-90SS99L
Rotary Actuator, Bore Size=10,rotation=90 with
auto switch
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Updated by: Hu dongyun on 5th Sep 2007
Rev B – Page 1 of 1
Prefix
Alphanumeric
Characters
64
Rubber Part
RU-X
Example Part Number Description
RU-45T-12.7W-15M Silicone Rubber 13MM Width
RU-H2256.016 Pad EH2256 (8) S16 with Spring Retainer
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
65
Shock Absorber
SA-X
Example Part Number Description
SA-RBC1411S Shock absorber, RBC1411S
SA-RBC1412S shock absorber, RBC1412S
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
66
Sensor
SE-X
Example Part Number Description
SE-329986-B3 Linear Encoder - LS476-370mm-10 fold
interpolation-TTL-3um-+5V-60m/min
SE-EE-SX-671 PhotoMicrosensor - L shaped Sensor - PNP - Light
ON - 50mA
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
67
Spring
SG-X
Example Part Number Description
SG-SSC-020A-13S Compression Spring SSC-020A
OD=3.05,WD=0.51,L=28.58
SG-SSC-067GH-3S Compression Spring, SSC-067GH-3S
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
68
Socket
SK-X
Example Part Number Description
SK-2WAY-3PIN-SOCKET 2 Way 3 Pin Socket
SK-PF083A-E Socket, 8-pin bottom surface or track mounting, top
screw terminals, molded standoff ring
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
69
Software List
SL-XXXXX
Example Part Number Description
SSL-TM-55 Software list for TM-55 TBF Final Bond Machine
Generated by: Hu Dongyun on 6th Jun 2009
Rev A – Page 1 of 1
Prefix Machine Model
70
Software Package
SP-X X
Example Part Number Description
SP-LABVIEW6 Labview 6 Development Package
SP-VSTUDIO6 Microsoft Visual Studio 6
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Version number
Software name
71
Screw
SR-PH-M4X20HS-X
1 Symbol Description Diagram 2 Symbol Description Diagram
H Hex
S Socket Head
P Philips
B Button Head
S Slot
P Pen Head
O Others C Countersunk
H Hex Head
O Others
3 Symbol Description 4 Symbol Description
- Inches H Half Thread
M Metric F Full Thread
S Self
Threading
O Others
5 Symbol Description
N Nylon
S Stainless
Steel
M Mild Steel
O Others
Example Part Number Description
SR-SB-M3X10FS Slot, Button Head Screw, M3X10, Full Threaded
Stainless Steel
Prefix
Pattern
Type (1)
Head
Type (2)
Unit Of
Measurement
(3)
Size
Length
Thread
Type
(4)
Material
(5)
Series
Numbers /
Alphabet
72
Switch
SW-X
Example Part Number Description
SW-M10EST41 Switch, Selector 4 Way Type TELUX
SW-MS500-AB Switch, Toggle, SPDT ON/OFF
SW-SW198 PLUG-3 PIN 13MP
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
73
Thermocouple
TC-X
Example Part Number Description
TC-A00-KE24FG01-
Q02B2701
Thermocouple, TypeK SpotWeld FiberGlass 1ft
AWG24
TC-236-3921 Thermocouple, TypeJ ExtensionCable25m Screened
PVC Insulated
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
74
Transformer
TF-X
Example Part Number Description
TF-192-70-4F-1 Transformer, Metto Part 192-70-4F/230/0--1.4-1.0-
0.8
TF-200-60-6F-36 Transformer, Metto Part 200-60-6F-36 230V-1V-
1.2V-1.4V
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
75
Terminal
TL-X
Example Part Number Description
TL-260306 2-conductor terminal block; lateral marking
horizontal
TL-IN13SBK-C Terminal block, 3 circuit poles with cover
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
76
Work Instruction
TWI73PD XX
Example Part Number Description
TWI73PD10 Hardware Setup and Calibration Procedure for TM
28M/S
TWI73PD26 Hardware Setup and Calibration For Temperature
Measurement (MKIII Machine)
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix Number
77
Valve
VA-X
Example Part Number Description
VA-A05RD25-1P-M5-E-SF Valve Double Soleniod, 5/2 Way, Adex
VA-L-VHS2000-02 Valve Pneumatic Sliding Type
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
78
Vacuum Accessory
VC-X
Example Part Number Description
VC-ZU05S Vacuum Ejector, In-line Style
VC-ZX1102-K35LZ-F Vacuum ejector system with suction filter, ZX1102-
K35LZ-F
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
79
Vibration Machine Mount
VM-X
Example Part Number Description
VM-TD30-25 Anti Vibratory Shock Absorber
Note: The alphanumeric characters are the same as the vendor’s part number. The
characters’ length is limited to 20.
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix
Alphanumeric
Characters
80
Variable Resistor/Varistor
VR-X - X - X
Example Part Number Description
VR-10K Variable Resistor multi turn 10Kohms 3296W-Top
Adjust
VR-1K-P Potentiometer Linear 1K (RoHS)
VR-470K-P-SW Potentiometer 20mm 400mW 470K PanelMount
with Switch
Generated by: David Lim on 19th Jun 2007.
Rev A – Page 1 of 1
Prefix With/without switch
Resistance Value With/without
potentiometer
81
Wire
WR-SA14-BW-X
1 Symbol Description 2 Symbol Description
S Solid Core A AWG
M Multi-strand T Thickness
E.G.: 24 AWG = A24
2mm Thick = T2
3 Symbol Description
BK Black
BL Blue
BN Brown
BW Bare Wire
GN Green
GY Green/Yellow
OE Orange
RD Red
YW Yellow
GY Grey
WT White
Example Part Number Description
WR-SA14-BW Solid core, 14AWG bare wire
WR-ST2-BW Solid core, 2mm thickness bare wire
WR-MA18-BL Multi-strand, 18AWG blue
Generated by: Lawrence on 14th Oct 2003.
Revised by CK Ong on 16th Oct 2006.
AWG / Colour (3)
Thickness
(2)
Prefix
Solid Core /
Multi-strand (1)
Series number /
Alphabets
82
Washer
WS-M3S-X
1 Symbol Description 2 Symbol Description
- Inches F Flat
M Metric T Star
S Spring
O Others
Example Part Number Description
WS-M5S Washer, M5, Spring Washer, Stainless Steel
WS-M3F Washer, M3, Flat Washer, OD=6, THK=1
WS-M4T Washer, M4, Star Washer, Stainless Steel
Generated by: Daniel Teo on 16th Oct 2003.
Rev A – Page 1 of 1
Prefix
Unit Of
Measurement
(1)
Size
Type
(2)
Series
Numbers
/
Alphabet
Please don't let the music stop...


okay.... long tym nvr post here....
was actually uite lazy actually....
okay....
this shd be my first dae of holidae....
but unfortunately....
it is also my first dae of attatchment....
actually i was supposed t get into AMD
but somen\how i was posted to TRI MECH TECHNOLOGIES PTE LTD.
anywae jus live with it.....
life is always full of unexpected stuffs....
but not too bad....
first dae nth much for me to do....
yeah! so i am here to blog....
wake up at 6.15am....
supposed to wake at 5.55am....
but nvm....
nt too bad....
then i went bathing, rushing to bustop...
then change bus from cwp....
to eunos link....
then change again....
to trimech....
finally reach my destination....
almost 2 hr....
okay....
i get my access card....
my own work station....
and....
PC....
yeah...
damn tired now sia....
blog again when i'm free...
bb!

Labels: IMS

Please don't let the music stop...


okay.... i'm damn damn damn dissapointed!!!
jus effing dissapointed!!!!
i mean okay...
i'm lyk....
okay we're lyk jus a small wooden floating boat in the big oceans.....
and the ripples of the waves never seems to calm down....
it's lyk we're going to get drown by some effing ripples.....
jus lyk....
we're struggling lyk wat man?
it's lyk i mean it's good to show concern but nt to put's one's shadow over others....
firstly it's selfish....
secondly, it's jus a act of destroy...
thirdly, it's a devil's doing....

yeah....i'm seriously damn dissapointed....
yeah....i've done my best....
let the rest lies in god's will then....


for believing god only help those who help themselves

*CHEERS* man
let's drink to our hearts fill.....

Labels: drink up....

Please don't let the music stop...


okay....
nth to blog...
feeling the monday blues...
don't feel like blogging...
emo-ing in progress...

Labels: monday blues

Please don't let the music stop...


okay... these photos are fishing trip on wed... went with my SWEETIE! yeap...
a beautiful place...
a perfect place for your soul partner...
a peaceful peace....
a place for to relax... bring no stress there! yeah!
okay...
todae abit tired...
not today...
is this few days... having some prob here...
with my parents...
why can't it stop?
but anyway i shd not rant too much!
atleast i still have a parents to scold uh!
i still got someone to vent my anger on!
wakakak! kidding!
i should thank god and count my blessing day by day!
so peep!
count YOUR blessing!
u're fortunate to know me!
yeapyeap....
went to church for the past 2 sundays!
yeapyeap!
quite fun!
i'm seeking comfort spritually and emotionally through his words!
yeapyeap!

Labels: lovelove

Please don't let the music stop...


mhmm...
yeap i was ONE FREAKING year older now....
hopefully one more year wiser...
but somehow... i dun think so...
mhmm...
todae i shd just purely blog about happy moments... jus setting aside the unhappy ones...
yeap....
yeaterday i went to celebrate my birthday with my gf and friends....
First and foremost, I want to thank everyone who had turned up yestersdae... thanks! i really appreciate it...
THANKS FOR SETTING ASIDE YOUR BUSY SCHEDUE TO CELEBRATE MY BIRTHDAY!!!
Secondly.... Thanks for all your gifts...

yesterdae, i met my gf at cwp at 10.50am....
brought her to toast box to have b'fast...
and she make me crack an egg!
it's lyk WTH... she know i hate egg...
and i still did it...
but i lyk hold the egg damn hard...
so it actually dirtied my finger...
wahaha...
so i went to wash it....
yeap...
then we took bus to TENPENIS....
wakakak...
went to tampines one to walk walk...
saw fartin there with her bf... look so sweet...
then after tt went to douby gout to buy tickets for movie...
after buying the tickets we went for lunch at ASTON...
my sweetie dun let me eat greezy stuffs...
tt's why i ate the black pepper chicken with cloewsaw and corn....
yeap... quite healthy...
after that we went walking around...
and sweetie say she wants to eat ben's and jerry...
and she actually gave me a surprise over there...
she asked the waitress over at bens and jerry to gift me a gift saying it's my secret admire gave it to me...
i was lyk shock and stunned for a moment...
bloods from all over the body gathered at one place...
they all rushed to my head for a meeting on wat's happening....
yeap...
ltr i found out...
it was from my SWEETIE!!!!
thanks sweetie!
i told you before...
the most precious gift i got for my 19th b'day isn't any one of the gifts i recieved or you gift....
but it was your love...

yeapyeap...
after tt we went to the cinema...
watched the show "MONSTER VS ALIEN"
after that we went to vivo for dinner...
went to dian xiao er...
was quite a scene...
3 tables....
after that we went to play arcade...
my initial plan was to climb up the mount faber....
but everyone was too tired...
so tt plan was aborbed...
maybe be next yr bah...
this year is my last year of being a teen...
next year i need to grow older again...
no longer a teen anymore...
so let me jus enjoy being a teen as much as i can now...
yeap...
after arcade...
i sent sweetie home...
and i went home to sleep...
tt's abt it...
yeapyeap...

Labels: how i wish it never ends....

Please don't let the music stop...


okay....
i've been emo-ing since last night....
was kinda depress....
relationship is one of the issues....
addition with peer stress...
work load and many others....

firstly...
ppl out there i must emphasize love is just between both of u....
just you and ur gf/bf....
why let other's poison ur mind....
you see... it's not easy for both parties to get along since start....
maybe when there's another person coming ahead...
you may sense it alr....
just that you won't let the opposite side know u know what is happening...

from last night,
i've been thinking through...
what if tomorrow i wake up and find that the girl i love is gone?
what will i be facing then?
so where do i get the courage to continue?
i've been through this over and over again....
i hate it！
and i seriously hate it....
why does it seems to be so short....
it seems lyk it won't last....
if you still see nothing ahead...
then my struggle thoughout all these months are meaningless....

i want to know the truth...

Labels: truth

Please don't let the music stop...


well....
todae was a laughing day....
i dunnoe why i kept laughing lyk i've jus taken ganjar....

todae is a depressing day i guess....
jus fuck it....
dun mention anymore....
bye bye!

Labels: is that the end?

Please don't let the music stop...


jus some random pictures...



wahaha....
hello world!
seriously... this few daes u can see me smilling lyk some crazy guy....
hahaha...
there're reasons behind it...

so... yesterdae i went bugis with the girl i love....
we went to catch a movie... "The ramen girl"
haha quite funny... yeap... her laughter was damn loud... as loud as mine!
wahaha...
i shall not post her photo here for some reasons...
i jus keep it for my own appreciation... wahahah....
yeap...

i finish sch quite early cause i did my assignment fast enough...
then i went singing with lim hui ming again...
as usual...
then i went to cwp to wait for her...
we took 960 to bugis...
long ride but we love it....
then we reach bugis...
we took afew mins to make up our mind on which movie to watch....
and she can't make decision...
so i chose...
yeap... the ramen girl...
then we went to lai lai hong shao niu rou mian restaurant...
nice place...
shd try the curry rice... not too bad...
then after the meal we went into the cinema...
in the theatre... her hands were cold and she was bring her hand to her mouth...
i held it tight....
it was cold, soft and small...
when i held it...
it's lyk we've forgotten the world...
just sitting in the cinema watching the movie and enjoying the moment of two...
her heartbeat raced when i held her hand... haha she's so cute...
and when i send her back...
she lay on my shoulder and sleep...
how i wish we could stay there in this moment forever...
but somehow.... todae... her neck ache i think...
maybe i too tall.... wahaha....
then when she reach her hse she alighted...
and i continued my journey home....

todae i went to my dad's factory as usual...
from morning i start to dismental the jet of the escavator crawer chain...
it's lyk damn hard lah...
it was stucked...
so i still managed to get tt damn stainless steel rod out of that hole!
wahaha...
then i went to jurong island "oil tanking" to repair aircompressor...
the diaphram burst...
but i took the wrong spare part...
so i went to goldbell at benoi rd to buy the DIAPHRAM...
then i go banly spare part to get a side mirror at pioneer rd north
cause someone hit my truck...
i went back to jurong island to repair again...
i went to oil tanking first to get the diaphram done....
then went to chat with Ah Chua for a while...
see wheather is there any up coming project and and feedbacks...
then went to samsung site to repaired the truck...
then deliever the 2 machines...
then check the generators over there...
then went back to office...
when i went back to office i chatted with her over msn...
and we were lyk keep on smilling to the lappy...
my workers tot i siao one...
her cousin also thought she siao alr...
but i guess only we know wat are we smilling abt...
wahaha....
yeap...
then went home and now, i think i blog finish...
MOOD: over the moooooooooooooooonnnnn

在人潮汹涌的巴士上，既然还能找到属于你我二人的世界。。。

Labels: loving the scent of ur's...

Please don't let the music stop...


hello people.....
okay... talk abt todae....
todae i got speed dating... it was err.... okay....
yeap... so recently i've been busy...
last sat went back to factory after so long...
went back to repair a small and a big truck....
after tt went down to orchard...
taka again...
i've been lyk going there every sat for lyk a month plus alr?
yeap...
so i hope i get a break soon....
feeling lyk damn stress nw....
cause in another 2 more weeks....
it's my MST alr...
so must study hard!
i'm trying very hard to pull up my GPA....
ya luh....
todae....
kena caught smoking in school...
by the security guard....
so it's lyk damn suay lah....
so troublesome....
need to go clinic then wat smoking rehabit centre and stuffs....
pay fine... meet the director....
1 word!
suay!
this few days had been quite okay for me... quite happy... but not this 2 daes...
i jus can't smile... some random thoughts....
and this few nights i've been having nightmare....
yesterdae it seems so fine...
but todae was horrible...
if i can turn back to yesterdae...
i rather not sleep at all...
i dun wish to past yesterdae and come to todae...
okay lah....
i shall stop here....
damn tired....
mood: moody...

Labels: wah... fined again... sian diao...

Please don't let the music stop...


haha.... okay back here!

(A) so how's ur day alex?
not to bad i guess, i guess i'm loving her even more!

(B) why do you have sleepless nights?
stress i guess... work, plans, random thoughts, business? yeap!

(C) what are the stresses you face recently?
-work-homework? can't cope well? plus i have lots of outside courses to take?
-own expectation? i wanted to be the one-eye of the blind.
-plan? own future plans? and maybe for my love!
-random thoughts? mhmm... good questions but i can't really answers... at times it may be about solar storms, the recent swine flu?, and maybe how wide and deep my love can grow for one girl?

(D) business? so what business are you in now?
by right i can't go into any business now as my parents object, cause thay want me to focus on my diploma, but i'm running afew blogshops now... so yeap!

(E) so what did you did today?
errm... i went to get my Safety Lifting Supervisor Course... and i guess someone's luck motivate me lyk alot? yeap!

(F) so what other out-of-school courses are you planning to take?
Safety co-ordinator, safety consultant, professional engineer? from B.C.A.

okay... that was a little convo with I, me and myself
yeah... abit random... yeah.... haha

okay so today was tiring but yeah! happy!
i want to be happy everyday!
i wanna learn how to smile naturally....
somehow i forgot how to smile alr....
yeap! so anyone teach me how?

okay update about yesterday....
okay i woke and did nothing untill about 11am....
i cook for my siblings
Yang Zhou friend rice and
Fu Yong egg...
jus a simple meal then i went to sleep...
then went orchard to market some products....
then went home... was abit emo yesterday so i didn't sleep cause it's not healthy to bring my own emotions to sleep... yeap....
so i went jalan jalan then wash up at 7.30
then go tat hong....
then 3.30 was my exam....
by right shd end at 5.30...
but i went off at 4pm cause i did it fast enough and check when i turn back....
everyone was still struggling lor!
haha

yeap! i shd end it here then... i need to go n bath
my dad is nagging lyk my granny!
haha
okay...
bye peep!

emotions: cheerful!

Labels: love you pigglet

Please don't let the music stop...


yeap!yeap!
hahahaha
i'm back here again....
went out with _ _ _ again!
haha...
okay... we went to orchard...
i reach shaw hse at 1320?
yeap...
then go and buy the tickets...
actually it's couple seats...
but i didn't pull up the hand rest...
so it's still normal seats....
haha
okay...
after that we went jalan jalan at taka...
brought her to Puma...
intro my friends to her...
then wait for kn to come...
then we go and have dinner...
dinner at crystal jade...
saw jessica with her new bf...
yeap...
after that we went to wisma atrium....
as you guys shd noe...
gals lyk shopping...
but they make my life more interesting...
yeap...
while they shop at cottonon i went to puke...
as usual...
my body is giving me prob...
after that went back...
then shop again...
then they went to buy concession...
then i took cab and send her back...
till now... she still dunwanna let me know where she stay...
i mean blk number...
in the cab...
i held her hands at some point of the journey....
at that tym...
how i wish the clock can stop tick-toking...
haha
jus sit back...
very stress-free... hold her hands and jus forget the time...
but...
reality is always cruel...
she had to go off soon...
so i went back
went to admiralty mtr there to get my sis her b'dae cake...
so yeah!
HAPPY BIRTHDAY SIS!
so u're 20 now...
so... grow up arh!
dun give me trouble!
try to get a new bf or go on with hym!
jus let me have some freedom yeap?
haha...

so let me round off...
todae i'm extremely happy!

Labels: 刚才，在车里传来了一阵不可思议的幸福。。。

Please don't let the music stop...
